Mega 150 Watt RV Solar Panel (Rich Solar)


Fits Offgrid DIY solar projects, Offgrid Tiny Homes, Offgrid VanLife
Smallest Size Offgrid Solar Panel with Best Performing Efficiency
20% Smaller than previous models

Dimensions 58.7 x 26.8 x 1.4 in


5 buss bar solar cell configuration
Lightweight anodized aluminum frame
High Transmission, AR (anti-reflective) Coated Tempered Glass
Plug and play junction box
Industry standard quick connect cables work in series or in parallel
Certified to withstand challenging environmental conditions
Excellent low light performance on cloudy days, mornings and evenings


Easy installation and handling for various applications (high-end off-grid and mobile applications)
Pre-drilled holes compatible with ground mounts, Z brackets, pole mounts and tilt mounts
Compatible with on-grid and off-grid inverters


25 year limited power output

Built-in Components

RICH SOLAR 150 watt monocrystalline solar panel
Panel leads (pair): 3 feet each
IP65 rated waterproof junction box
IP67 rated waterproof solar connectors
Bypass diodes built-in the junction box


Maximum Power(Pmax): 150W
Maximum Power Voltage(Vmp): 19.5V
Maximum Power Current(Imp): 7.69A
Open Circuit Voltage(Voc): 22.8V
Short Circuit Current(Isc): 8.06A
Maximum System Voltage(Vmax): 1000VDC
Temperature Range: -40°C ~ 90°C
Weight: 17.8 lbs
Dimensions: 45.1 x 26.8 x 1.4 in
