Product Overview
MODEL: GP-PV-190M
The Go Power 190 watt Solar Panel is a high-efficiency monocrystalline solar module that provides outstanding performance and cost-effective solar power for high-end off-grid and mobile applications. This solar module is built to last and features a 25-year limited power output warranty.
To ensure long life, the high-efficiency solar cells are encapsulated between a special tempered, low-iron solar glass and a Tedlar/polyester backing material. The mounting frame, manufactured from anodized marine-grade aluminum, allows the GP-PV-190M to be installed in extreme conditions.
The GP-PV-190M is ideal for:
RV/Marine
12/24 Volt battery systems
OEM
Security Trailers
Telecommunications
Stand-alone or grid connected applications
Signaling systems
Remote telemetry
Water pumping
Other off-grid applications
Product Specifications
Module Specs
| Solar cell type | Monocrystalline |
|
Output power
|
190 W
|
|
Rated current
|
9.3 A |
|
Rated DC voltage
|
19.1 V
|
| Open-circuit voltage | 22.5 V |
| Module efficiency | 16.4% |
| Connectivity | MC4 connectors |
| Frame type | Clear anodized aluminum frame |
| Certifications | CE |
| Dimensions | 59.06 x 26.3 x 1.59 in / 1500.12 x 668.02 x 40.38 mm |
|
Weight
|
26.4 lbs / 12 kg
|
|
Warranty
|
25 years power output (module)
|
